Galvalume Steel Strip is a high-performance, corrosion-resistant metallic material. It is produced by hot-dip galvanizing an aluminum-zinc alloy coating onto a steel substrate, followed by slitting. The resulting surface exhibits a unique bright silver, scaly pattern, combining the durability of aluminum with the edge protection of zinc. It is widely used in construction, home appliances, and many other fields.
Galvalume Steel Strip for Sale
Wanzhi Group provides raw material production and deep processing services for galvalume steel strip, and offers OEM and ODM services for galvalume steel coils, sheets, corrugated steel, pipes, strips, profiles and other GL materials products to factories, project construction companies and traders.
Specification
| Specification | Details |
| Thickness | 0.15mm – 3.0mm |
| Width | 4mm – 1250mm |
| Length | Specified (as required) |
| Precision | ±0.1mm |
| Coating Weight | 30g/m² – 150g/m² (customizable) |
| Surface Treatment | Passivation / Oiling / Paint Sealing & Anti-fingerprint / Phosphating |
| Packaging | Plastic Film + Moisture-proof Paper + Galvanized Iron Sheet |
| MOQ (Minimum Order Quantity) | One roll |
Performance
| Performance Indicator | Galvalume (Aluminum-Zinc Coated) Steel Strip |
| Corrosion Resistance | 2-6 times longer lifespan |
| Maximum Operating Temperature | 315℃ (long-term) |
| Thermal Reflectivity | >0.70 |
| Yield Strength | 230-400MPa |
| Tensile Strength | 230-550MPa |
| Elongation | 15-45% |
Galvalume Steel Strip Advantages
Corrosion Resistance: Galvalume steel strip offers 2-6 times the corrosion resistance of ordinary galvanized steel strip.
Heat Resistance: It withstands long-term use at temperatures up to 315°C without discoloration, and its color change after 120 hours at 300°C is significantly lower than that of aluminum-coated steel.
Heat Reflectivity: Reflectivity > 0.70, twice that of galvanized steel and exceeding the EPA Energy Star standard (0.65).
Mechanical Properties: Yield strength (230-400 MPa), tensile strength (230-550 MPa), and elongation (15-45%) are all superior to those of ordinary galvanized steel (yield strength 140-300 MPa, tensile strength 200-330 MPa).
Cut Edge Protection: The zinc content in the galvalume coating protects cut edges, scratches, and drilled holes.
Cost-Effective: With a comparable service life, the overall cost of galvanized steel strip is lower than that of stainless steel and pure aluminum.
Applications
Construction: Roofs, walls, garages, soundproof walls and ductwork, light steel keels (C/Z-section steel);
Appliance Manufacturing: Appliance back panels, frames, housings, ovens;
Automotive Parts: Mufflers, exhaust pipes, fuel tanks and truck bodies, chassis guards, insulation panels;
General Hardware: Greenhouse ducts, chimney pipes, lighting housings, heat exchangers, dryers, and water heaters;
Other: prepainted galvanized substrates
Why Choose Us?
Wanzhi Group boasts advanced hot-dip galvanizing production lines, precision slitting equipment, and automated control systems. We are ISO9001 certified, and our products comply with international standards such as ASTM, JIS, and GB. We provide high-quality metal materials and processing services to customers in over 100 countries and regions worldwide.
Galvalume Steel Strip Factory and Manufacturer
Located in Boxing County, Binzhou City, Shandong Province, China, our factory provides raw materials and additional services such as bending, slitting, flattening, forming, and painting for the construction, engineering, and home appliance industries. Our galvanized, galvanized, color-coated, aluminum alloy, and stainless steel strips are exported to over 100 countries and regions worldwide.
Customized Galvalume Steel Strip
Custom Size: Customize width, thickness, and length according to drawings.
Coating Control: Adjust the aluminum-zinc ratio and coating weight based on different corrosion environments.
Surface Treatment: We offer post-treatments such as fingerprint resistance, oiling, passivation, and painting.
Packaging Options: Stand-up and flat packs are available.
Case and Project
Our steel strips of various materials have been exported to over 100 countries and regions worldwide, including Turkey, Saudi Arabia, the UAE, Turkmenistan, Spain, South Africa, Vietnam, Chile, Peru, and Libya.
Galvalume vs. Galvanized: How to choose?
| Characteristic | Galvalume Steel Strip | Galvanised Steel Strip |
| Corrosion Resistance | Extremely strong, 2-6 times that of galvanized steel | Good |
| Heat Resistance | Can withstand up to 315℃ without oxidation | Poor, prone to discoloration |
| Appearance | Bright silver, uniform and fine | Zinc spangles visible, highly decorative |
| Cost | Moderate, high cost-performance ratio | Lower |
| Suitable Scenarios | High-temperature, high-corrosion environments, high-end appliances and buildings | General construction, low-end manufacturing industries |
