PPGI Panel

PPGI Panel is a highly customized and systematic product manufactured from PPGI coil through processes such as shearing and forming. It is widely used as a core cladding and structural component in steel buildings. Wanzhi Group offers one-stop OEM/ODM custom solutions—from panel design to finished product delivery—tailored to specific building locations, structural requirements, aesthetic preferences, environmental corrosion levels, fireproofing and insulation standards, and budget constraints.

CONTACT US

PPGI Panel for sale

Wanzhi Group PPGI Panel is designed for roofing, wall cladding, floor decking, and other applications. It withstands wind and rain, provides drainage and load-bearing capacity, and resists wind pressure, balancing performance, aesthetics, and installation convenience.

Roofing Systems

PPGI Small Corrugated Panel

• Features: Features a fine, dense wave profile with wave height typically <30mm. Its smooth lines combine structural strength with decorative appeal.
• Classic Models: YX10-100-800, YX15-225-900.
• Applications: Factory walls, agricultural shed enclosures, temporary fencing, interior partitions. Suitable for low-load-bearing, cost-sensitive projects.

PPGI Large Corrugated/High-Wave Panel

• Features: Rib height 25-40mm, pronounced wave height, large sectional moment of inertia. Superior structural stability compared to small-wave panels, exceptional load-bearing and drainage capacity, economical and practical.
• Models: Type 750, Type 840/900
• Applications: Preferred choice for large-area roofing in standard industrial plants, logistics warehouses, supermarkets, and open-air station canopies.

PPGI Standing Seam Panels

• Features: Standing seam connection technology, rib height 40-80mm. On-site mechanical interlocking without penetrating screws creates a continuous waterproof surface. Highest air and water tightness in the system, excellent adaptability for large spans.
• Applications: Commercial complexes, large-span public buildings. Suitable for projects demanding high waterproofing and aesthetic standards.

PPGI Overlapping/Capping Panels

• Features: Overlapping or capping connections, clean panel profiles, easy installation, modern appearance with crisp visual lines.
• Classic Models: YX25-210-840, YX18-76-914.
• Applications: Factory eaves, wall cladding, equipment access walkway enclosures, interior partitioning, canopies.

Wall Systems

PPGI Flat Panel/Microtextured Panel

• Features: Smooth surface or subtle textured finishes (orange peel, stone texture). Hidden fastener installation creates a pristine façade.
• Applications: Modern office buildings, factory exteriors, interior decorative wall panels.

PPGI Box Panels

• Features: High standing edges on both sides enable direct use as load-bearing components, offering quick installation and excellent rigidity.
• Classic Models: YX50-300-600, YX40-250-500.
• Applications: Container-style housing, mobile guard booths, temporary office walls/roofs, modular building components, high-end building exteriors.

Floor Deck Systems

PPGI Open-Flange Floor Deck

• Features: Open-rib design with trapezoidal cross-section, lightweight, replaces traditional formwork and concrete through shear stud bonding.
• Classic Models: YX76-344-688, YX51-200-600.
• Applications: Multi-story factories, mid-span building mezzanines, standard office floor decking.

PPGI Closed-Flange Deck Panels

• Features: Closed-flange design with sealed bottom section. Superior rigidity compared to open-flange types, enhanced fire resistance, and more uniform load distribution.
• Applications: Premium office buildings, commercial complexes, residential mezzanines, and hospital floors requiring high floor-to-ceiling clearance, fire protection, and aesthetic underside appearance.

PPGI Reinforced Truss Deck

• Features: Composite structure of PPGI sheet and reinforced trusses, suitable for large-span, heavy-load applications with exceptional load-bearing capacity.
• Applications: Large industrial plants, long-span structures, bridge ancillary structures, and projects requiring accelerated construction schedules.

Composite Functional Systems

PPGI Sandwich Panels

• Features: “Sandwich” construction with PPGI panels on both sides and continuous core filling of polyurethane, rock wool, or similar materials. Combines corrosion resistance, thermal insulation, soundproofing, and fireproofing capabilities with the fastest installation speed.
• Classic Products: Rock Wool Sandwich Panels, Polyurethane Sandwich Panels.
• Applications: Cold chain logistics, high-standard factory workshops and enclosures, cleanrooms, premium modular buildings, and various rapidly constructed insulated structures.

PPGI Panel Customization

Wanzhi Group offers the full range of PPGI panel products listed above and provides customized production based on your project drawings. Wanzhi Steel Factory delivers end-to-end customization from base materials to finished products, alongside professional OEM/ODM services.

Base Material Customization

Select from various grades of base materials according to structural requirements, including DX51D, DX52D, DX53D, DX54D, SGCC, SGCD standard substrates, and S220GD-S350GD high-strength structural substrates. Coating options include Galvanized (GI) and Aluminum-Zinc (Aluzinc), with coating weights customizable from Z30 to Z600.

Custom Specifications

Supports sheet thicknesses of 0.12-2mm, widths of 600-1500mm, and custom lengths. Coil weight, surface texture, rib height, and rib spacing can be adjusted to match project span and load-bearing requirements, accommodating diverse architectural dimensions and installation scenarios.

Paint Customization

Offers diverse paint systems including PE polyester paint (universal, rich colors), HDP high-weathering polyester paint (strong UV resistance), PVDF fluorocarbon paint (high corrosion resistance and weathering), plus PVC, PU, and more.

Color Customization

Supports full RAL and Pantone color systems with adjustable finishes including matte, gloss, and metallic effects. Special colors (metallic, wood/stone imitations) available upon request.

Surface Customization

PPGI surfaces can undergo anti-fingerprint treatment, film coating, embossing (wood grain, stone texture), and printing (wood grain, marble, sky, floral, other natural/cultural landscapes).

Application Customization

Panel profiles and connection nodes are reinforced based on specific building locations (roofs, walls, interiors), environmental corrosion levels (inland/coastal/industrial zones), local wind/snow loads, seismic requirements, and fire/thermal insulation standards (Class A/B1 fire rating).

PPGI Panel Packaging

Wanzhi Group employs export-grade rust-proof packaging standards, providing customized packaging solutions tailored to the characteristics of different PPGI steel sheet types. This prevents shifting, moisture exposure, panel scratches, deformation, and rust during transportation.

Standard Packaging (Applicable to Most Flat Sheets and Coils)

• Rust-proof Separation: Protective film or kraft paper padding between PPGI panels.
• Integrated Bundling: High-strength steel strapping secures entire pallet load to fumigated wooden pallets.
• Waterproof Outer Covering: Entire load wrapped in waterproof woven fabric or corrugated cardboard, secured with steel strapping.

Reinforced Packaging

• Edge Protection: All corners reinforced with thickened paper or plastic corner protectors.
• Framework Securing: Custom steel transport frames for extra-long panels to prevent bending and deformation.
• Fully Sealed: Utilizing six-sided sealed wooden or metal crates.

Wanzhi Group provides global customers with a full range of PPGI Panel products and one-stop solutions. Whether you are a purchaser or contractor for industrial plants, commercial buildings, or modular projects, you can find suitable product solutions here. Contact us for samples, customized quotes, and technical support!
