PPGI Colour Coated Sheet

Wanzhi Group is PPGI colour coated sheet (Pre-Painted Galvanized Iron sheet) manufacturer and supplier from China, We provide prepainted steel for architectural and industrial applications in accordance with international standards such as ASTM A755, EN 10169, JIS G 3312, etc. We offer slitting, bending, forming, stamping, and other further processing for roofing, walling, decorative, piping, and structural steel applications.

Substrate: Galvanized, Galvalume
Material: PPGI, PPGL
Sheet: Flat sheet, corrugated sheet, corrugated sheet, trapezoidal sheet, sandwich panel, etc.

CONTACT US

PPGL PPGI Colour Coated Sheet

PPGI Colour Coated Sheet for Sale

Wanzhi Group produces PPGI color coated sheet in various colors and shapes, with 3 lines of prepainted steel, slitting machines, forming machines, etc. We can produce the sheets according to the specified sizes and specifications and provide design and production services according to the application requirements. We can produce according to the specified size and specification, and we can also provide design and production services according to the application requirements. (At the same time, we also support the customization of shaped peaks, special curves, or composite structures)

Corrugated Roofing Sheet
Color Coated Steel Sheet

Shape

Profile Type Specifications
PPGI Corrugated Profile Cover Width between 600-1,000mm, compression-resistant and drainage-resistant roofing sheets, suitable for industrial plants, warehouses, agricultural greenhouses, and other applications.
PPGI Concealed Fix Profile Effective Cover Width: 300-600mm, good waterproofing for building facades, suitable for commercial buildings, stadiums, etc.
PPGI High Rib Profile Effective cover width: 800-1,200mm, high structural strength roofing panels, suitable for large-span building structures.
PPGI Tile Effect Profile Effective cover width: 300-500mm, lightweight and decorative, suitable for villa roofs, renovation of ancient buildings.
PPGI Sinusoidal Profile Effective coverage width: 600-1200mm, good wind resistance, suitable for public utility roofs, noise barriers, solar panel bases and other applications.

PPGI Colour Coated Sheet Suggestions

  • High wind pressure/snow load → high crested sheet or trapezoidal sheet
  • Commercial building → concealed sheet; antique project → corrugated sheet
  • Large span structure → high crested sheet (large purlin spacing)
  • Rainy area → trapezoidal sheet with high wave height or sinusoidal sheet
  • Economic project → standard trapezoidal sheet

Specifications

Parameters Typical specifications
Thickness of base sheet 0.12mm -1.5mm
Galvanized layer weight Z30-Z350 (60-275g/m²)
Coating thickness Top side 10-40μm, back side 5-20μm
Plate width 600 -1,250mm (customized)
MOQ 10 tons
Coil weight 3–10 tons (customized)
Standards ASTM A755, EN 10169, JIS G 3312
Delivery time 5–45 days

PPGI Colour Coated Sheet Price

The price of PPGI Colour Coated Sheet is composed of PPGI steel cost and sheet molding and processing cost, the price of regular PE coating PPGI coil is 600-700USD per ton, the price of choosing different materials such as SMP, PVDF, HDP, PU and so on, the price of different degree of fluctuation of the paint coating. The price of PPGI sheet varies greatly with different sizes and surfaces. Leave a message to tell us the specification of the sheet you need and get a free quote!

PPGI PPGL Panel - Prepainted Steel Sheet Supplier
PPGI PPGL Panel

PPGI Colour Coated Sheet Properties and Applications

PPGI colour coated sheet combines the mechanical properties and characteristics of galvanized steel and organic coatings to enhance the mechanical strength, drainage, and aesthetics of the steel sheet, making it widely used in residential, commercial, industrial, and other buildings, manufacturing, and other areas.

Properties

Properties Parameters/Characteristics
Substrate Strength Tensile Strength 270-550 MPa, Yield Strength 140-350 MPa
Coating Adhesion Scratch Test Grade 0-1
Flexural Properties 0T-2T Flexural Crack Free
Impact Resistance 50 -90 cm-kg
Temperature Resistance -50°C to +120°C stable
Salt Spray Test 500-1,500 hours without red rust

Core Benefits

Property Description
Corrosion Resistance Zinc + PE/SMP/PVDF/HDP/Epoxy Coating Double Protection
Decorative Customized colors available, surface gloss available (high gloss, matte, embossed texture), pattern available wood grain, floral, marble pattern, brick-like pattern, grass, sky, etc.
Processability Suitable for stamping, bending, molding, crimping, and other processes, the coating will not crack
Environmental protection Comply with RoHS, REACH, and other regulations
Economical Factory pre-coating, cutting, and molding processes reduce on-site construction costs and maintenance frequency

Applications

Industries Typical uses
Architecture Roofs, walls, facades, floor slabs, garage doors, noise barriers
Home Appliances Refrigerators, washing machines, and air conditioning housings
Industry Shelving, electrical cabinets, ventilation ducts, and solar racks
Transportation High-speed rail interior panels, container housings

Comparison of PPGI, PPGL, ZAM, etc.

Material PPGI PPGL (Aluminum Zinc Plated Color Coated Sheet) ZAM Coated Sheet
Corrosion Resistance Excellent (Galvanized + Coating) Better (Aluminum Zinc Plated + Coating) Best (Zinc-Aluminum-Magnesium Plated + Coating)
Cost Low-Medium Medium-High High
Suitable Environment General Outdoor High Humidity, High Temperature Extremely Corrosive Environment

PPGI Colour Coated Sheet Manufacturer – Wanzhi

Wanzhi Group is a PPGI color-coated sheet factory manufacturer from China. Our factory is ISO certified, and we can provide different forms of metal materials, such as coils, sheets, roofing sheets, pipes, strips, etc., to provide the most cost-effective metal material solutions for construction and industrial production. We offer the most cost-effective solutions for construction and industrial production. Our GI, GL, PPGI, PPGL, ZAM, etc. coated steel materials have excellent corrosion resistance, weathering resistance, durability, durability, fire resistance, machinability, etc. We can also provide free samples of conventional coated steel materials.

Production line of Prepainted Coil Sheet
Production line of PPGI
