Aluzinc AZ100 is an aluminum-zinc coated steel sheet manufactured in accordance with standards such as EN 10346 and ASTM A792. It features a 55% aluminum-zinc alloy coating with a total weight of 100 grams per square meter on both sides. Wanzhi Group manufactures the full range of Aluzinc AZ100 and other coated steel products, offering cutting and forming services to meet project-specific dimensions and shapes.
Aluzinc AZ100 for Sale
The weight of the aluminum-zinc alloy coating directly determines the service life and environmental suitability of the steel. AZ100 aluzinc steel sheets and coils offer a lifespan of 15-50 years. With the advantages of “medium-to-high corrosion resistance + high cost-effectiveness,” they have become the preferred corrosion-resistant metal product in the construction and industrial sectors.
Product Specifications
| Base Material | DX51D+AZ, S350GD+AZ |
| Coating | AZ100 (100g/㎡, total for both sides) |
| Thickness | 0.12 mm – 3.0 mm |
| Width | 600 mm – 1500 mm |
| Form | Steel coil, flat plate (can be cut and formed as required) |
| Surface Treatment | Chrome-free passivation, oil coating, fingerprint-resistant |
| Surface Condition | Regular zinc crystal pattern |
| Further Processing | Paint coating (AZ100 PPGL Steel) |
Aluzinc AZ100 Pricing
The price of aluzinc steel primarily depends on substrate thickness and grade, coating weight (AZ value), surface treatment method, and raw material market prices. Taking DX51D+AZ100 with thicknesses ranging from 0.3mm to 2.0mm as an example, the current price range is approximately $700–900 per ton. For thicker specifications (>3.0mm) or custom products with special requirements, please send detailed inquiries to info01@wanzhisteel.com for a free quote and product catalog!
Application Areas
AZ100 aluzinc coated steel is suitable for moderately corrosive environments. Its exceptional corrosion resistance combined with the excellent formability of cold-rolled or hot-rolled steel makes it an ideal choice for numerous projects requiring long-term durability.
- Building Envelope: Roofing and wall cladding in coastal or high-humidity regions
- Appliance Manufacturing: Outdoor air conditioner housings, premium appliance back panels
- Agricultural & Industrial: Greenhouse structures, industrial facilities
- Automotive & Infrastructure: Automotive components, highway sound barriers
AZ100 GL vs. Z100 GI
| Comparison Dimension | Aluzinc AZ100 (55% Al-Zn) | Galvanized Z100 (Pure Zinc) |
| Coating Composition | An alloy coating consisting of 55% aluminum, 43.4% zinc, and 1.6% silicon. | A coating with over 99% pure zinc. |
| Corrosion Protection Principle | Dual protection from aluminum and zinc. | The zinc layer protects the substrate through self-consumption. |
| Corrosion Resistance | Approximately 2-6 times more corrosion-resistant than galvanized coatings. | Weaker than Aluzinc. |
| Appearance and Characteristics | Bright and uniform silver-gray color, higher surface hardness, more scratch-resistant, and excellent heat resistance. | Grayish-white color, relatively soft surface, and poor heat resistance. |
| Typical Suitable Environments | Moderately corrosive environments: such as high-humidity inland areas, mild industrial zones, coastal areas, and strong ultraviolet environments. | Mildly corrosive environments: dry or indoor environments, general industrial areas without chemical pollution. |
| Service Life (Outdoor) | 18-25 years. | 7-15 years. |
| Cost-Effectiveness | High initial cost. | Lower initial cost. |
More Aluzinc Material Options – Wanzhi Group
AZ50, AZ100, AZ150 are the best-selling specifications in Wanzhi Group‘s Aluzinc series. We have provided customized Aluzinc Steel solutions for numerous global projects including building facades, walls, roofs, bridges, chemical plants, and more. From production to processing and forming, Wanzhi Steel Factory offers one-stop services.
Aluzinc AZ100 Manufacturer
Wanzhi Group Factory, located in Shandong Province, China, is an ISO9001/ISO14001 certified metal supplier. We operate comprehensive production lines for aluzinc steel coils, galvanized coils, and color-coated steel coils, complemented by processing services including slitting, precision cutting, roll forming, and punching. Our annual production capacity reaches 600,000 tons. Our AZ100 aluzinc steel coils/sheets and color-coated aluzinc sheets are exported to over 100 countries and regions across South America, Asia, the Middle East, and Africa.
Quality Assurance
Prior to shipment, all products undergo rigorous testing including coating thickness measurement, adhesion testing, salt spray resistance, hardness testing, and chemical composition analysis to ensure performance compliance. Additionally, we support customer teams and authorized representatives in conducting factory inspections prior to shipment. Our products comply with international standards and customer requirements, accompanied by comprehensive quality inspection reports.
Packaging
Wanzhi Aluzinc steel coil and sheet standard packaging is 3-5 tons per coil, with export rust-proof packaging as standard (gas-phase rust-proof paper + plastic film + galvanized steel sleeves/corner protectors + wooden pallets). We customize coil weights, packaging methods, and labeling per client specifications.
Project Cases
Aluzinc AZ100 is a popular material for projects like mild coastal building roofs, photovoltaic racks in high-UV regions, and humid inland industrial plants. We supply GL and PPGL products in various thicknesses, dimensions, and grades to clients including roofing panel processors, overseas construction contractors, and appliance manufacturers.
Want to learn more about Aluzinc Steel grades and coating solutions for different environments? Or need detailed specifications and samples for Aluzinc AZ100 products? Leave us a message!
