Prepainted galvanized steel coil (PPGI) uses galvanized steel as the substrate and is widely used in roofing, construction, and home appliances. As a commonly used thickness, 0.5mm offers a good balance of formability and strength. Wanzhi Group operates three professional color coating lines and offers customized widths, RAL colors, zinc coating thicknesses, paint types, and other specifications.
- Width: 600mm-1250 mm, customizable
- Painting Types: PE / SMP / HDP / PVDF
- Grades: DX51D+Z / DX52D+Z / DX53D+Z / DX54D+Z / S280GD+Z / S350GD+Z / S550GD+Z, etc.
Specification
| Product Name | Prepainted Galvanized Steel Coil (PPGI) |
|---|---|
| Substrate | Galvanized Steel (GI) |
| Grades | DX51D+Z / DX52D+Z / DX53D+Z / DX54D+Z / S280GD+Z / S350GD+Z / S550GD+Z, etc. |
| Zinc Coating Weight | Z30 - Z275 g/m² |
| Thickness | 0.5 mm |
| Width | 600mm - 1250 mm (customizable) |
| Coil Diameter | 508 mm / 610 mm |
| Coil Weight | 3 - 5 tons, can be customized |
| Paint Type | PE / SMP / HDP / PVDF |
| Coating Thickness | Top: 11-35 μm ; Bottom: 5-14 μm |
| Paint Surface | Matte, glossy, wrinkled, embossed |
| Color | RAL colors (custom patterns available) |
| Standard | ASTM, EN, JIS, GB |
| Certificates | ISO, SGS, BV CE etc. |
| MOQ | 10 tons |
| Package | Standard export packaging, or as per your requirements |
0.5mm PPGI Coil Manufacturing Process
- Uncoiling: Uncoil the galvanized steel coil and prepare the strip for surface treatment.
- Cleaning & Pretreatment: Clean and chemically treat the strip to remove impurities and improve paint adhesion.
- Primer Coating: Apply a primer to enhance corrosion resistance and improve coating adhesion.
- Top & Back Coating: Apply the specified paint to both sides to achieve the required color, finish, and protection.
- Curing & Cooling: Pass the coated strip through a curing oven, then cool it to stabilize the coating.
- Inspection: Check dimensions, coating quality, surface condition, color, and mechanical properties.
- Recoiling & Packaging: Recoil the finished 0.5mm PPGI strip and package it for safe storage and shipment.
Pattern and Surface Finish of 0.5mm PPGI Coil
- Color & Pattern: RAL colors are available, with color matching based on RAL cards or customer samples. Custom patterns include wood grain, brick, camouflage, floral, marble, grass, traffic warning patterns, and other decorative designs.
- Surface Finish: Available finishes include glossy, matte, embossed, wrinkled, and textured surfaces, with customized finishes available upon request.
Paint Types
- PE (Polyester): Good color retention, flexibility, and cost-effectiveness. Suitable for general construction and indoor applications.
- SMP (Silicone Modified Polyester): Better hardness, UV resistance, and weatherability than PE. Suitable for roofing and exterior applications.
- HDP (High-Durability Polyester): Provides improved UV resistance, corrosion resistance, and color retention. Suitable for hot, humid, and outdoor environments.
- PVDF (Polyvinylidene Fluoride): Excellent UV resistance, weatherability, corrosion resistance, and color retention. Recommended for coastal areas and harsh outdoor environments.
How to Select the Right Paint for PPGI?
Paint Type by Climate
- Mild or dry climates: PE is generally suitable for standard construction and indoor applications.
- Hot and sunny climates: SMP or HDP is preferred for better UV resistance and weatherability.
- Humid or rainy climates: HDP provides improved weatherability and long-term durability.
- Coastal or high-UV environments: PVDF is recommended for excellent UV resistance, weatherability, and color retention.
Color Selection
- Light colors: Reflect more solar radiation and may help reduce surface temperature, making them suitable for hot and sunny climates.
- Dark colors: Absorb more solar radiation and may result in higher surface temperatures. They are often selected for architectural and aesthetic requirements.
Primer and Topcoat
- Primer: Select the primer based on adhesion, corrosion resistance, flexibility, and forming requirements.
- Topcoat: The topcoat provides the desired color and appearance while contributing to UV resistance, weatherability, and durability. PE, SMP, HDP, and PVDF are available for different performance requirements.
Benefits of 0.5mm Prepainted Galvanized Steel Coil
- Durable Protection: The galvanized coating and paint layer provide enhanced corrosion resistance and long-term protection.
- Good Formability: The 0.5mm thickness supports bending, roll forming, and other forming processes.
- Lightweight: The 0.5mm thickness helps reduce material weight while maintaining suitable strength for many applications.
- Attractive Appearance: Various RAL colors and surface finishes meet different architectural and design requirements.
- Good Heat Resistance: Selected coating systems offer good heat resistance and color retention.
- Solar Reflectivity: Light-colored coatings can reflect part of solar radiation and reduce heat absorption.
Applications
- Construction: Roofing panels, wall cladding, sandwich panels, ceilings, and partitions for buildings.
- Home Appliances: Refrigerator and air-conditioner panels, cabinets, and other appliance components.
- Furniture & General Products: File cabinets, display racks, doors, lampshades, and other metal products.
- Industrial Applications: Ventilation ducts, equipment covers, billboards, and other fabricated components.
- Transportation: Interior panels, partitions, and other lightweight metal components.
Comparison Between 0.5mm PPGI Coil and PPGL Coil
Both 0.5mm PPGI and PPGL coils are prepainted steel products with different metallic-coated substrates. PPGI coil uses galvanized steel with a zinc coating, while PPGL uses galvalume steel with an aluminum-zinc alloy coating. This difference makes them suitable for different environmental and application requirements.
| Item | 0.5mm PPGI Coil | 0.5mm PPGL Coil |
| Substrate | Galvanized Steel (GI) | Galvalume Steel (GL) |
| Corrosion Resistance | Good | Generally higher |
| Heat Resistance | Good | Better |
| Formability | Good | Good |
| Appearance | Similar; customizable | Similar; customizable |
| Cost | Medium | Medium–High |
| Service Environment | General environments | Demanding outdoor environments |
0.5mm Prepainted Galvanized Steel Coil Prices
The price of 0.5mm PPGI coils is mainly affected by steel substrate cost, zinc coating, paint type, dimensions and order quantity. Wanzhi Group maintains raw material inventory and a flexible supply chain, helping ensure stable supply and competitive pricing. PPGI coil prices generally range from USD 600–1,000 per ton, depending on specifications and market conditions. Please leave us your required specifications and quantity. We will provide an accurate quotation and customized solution based on your needs.
Prepainted Galvanized Steel Coil Supplier – Wanzhi Group
Wanzhi Group is an ISO-certified prepainted galvanized steel coil manufacturer in China, with over 10 years of production and export experience. Our factory (Wanzhi Steel) operates three PPGI production lines with a monthly capacity of up to 30,000 tons. Standard products are available from stock, while customized orders typically have a 5–45 day lead time. The factory is equipped with quality control and sample rooms for product inspection and sample testing, supporting diverse project and procurement requirements.
Quality Inspection
Wanzhi Group has established a comprehensive quality control system. Prepainted steel coils undergo strict inspections covering dimensional accuracy, surface quality, zinc coating and paint film thickness, coating adhesion, mechanical properties, and salt spray testing. Each shipment is supplied with a Material Test Certificate (MTC) and relevant inspection reports. Third-party inspections by SGS, BV, and other recognized agencies are also available upon request.
Services
- Deep Processing: Wanzhi Group provides slitting, cutting, bending, punching, forming, and profiling services to meet different processing requirements.
- One-Stop Support: Our team provides integrated support covering material selection, technical consultation, production, and delivery, with 24-hour online assistance.
- Steel Supply: We supply hot rolled and cold rolled steel, GI, GL, PPGI, PPGL, PPAL, corrugated sheets, Zinc-Aluminum-Magnesium (ZAM) steel, aluminum, stainless steel, and other steel products for diverse applications.
Package and Shipment
Color-coated steel coils and other coated steel coils are normally packed with plastic film, moisture-proof paper, and galvanized steel sheet for export. Galvanized steel straps, corner protectors, and wooden pallets can be added for enhanced stability and protection. These materials help protect the coils from moisture, corrosion, impact, and surface damage during storage and transportation. Customized packaging, including branded logo marking and vertical packaging, is also available upon request.
Global Cases
Wanzhi Group has supplied PPGI and PPGL coils and sheets to customers in more than 120 countries and regions worldwide. As a professional prepainted steel manufacturer, we provide color coated steel products in various specifications and finishes for different markets and applications. Based on each project’s climate, building function, design requirements, and budget, we provide tailored solutions to meet diverse customer needs.
Wanzhi Steel – Agricultural Greenhouse Project in Turkmenistan
550 tons PPGI Steel Coil to Azerbaijan
100 tons of Galvanized Coils to Saudi Arabia
144 ton Steel Wire to Spanish
Project of PPGI Roofing en Libya
100 tons of GL and PPGL in Solomon Islands
Customer Visits
Wanzhi Steel has welcomed customers from 40+ countries and regions, including Turkmenistan, Kazakhstan, Peru, Russia, Indonesia, Turkey, and Saudi Arabia. Visitors can tour our coated steel production lines, quality inspection room, sample room, and offices to learn about our products, production processes, and quality control. We welcome customers to visit our factory and explore PPGI, PPGL, PPAL, and other coated steel solutions.
Color coated steel coils and sheets combine corrosion protection, durable finishes, and attractive appearance, making them suitable for construction, manufacturing, and other industrial applications. For product specifications, mechanical properties, or export case details, please contact us for more information and a tailored quotation.
