PE PPGL Coil is currently one of the most popular color-coated steel sheets (PPGI/PPGL). PE (Polyester) coating offers the widest application and highest cost-effectiveness. Popular products include PE PPGI and PPGL Steel. It primarily refers to polyester coating on the front side, with the back typically coated in PE or the more economical epoxy coating.
PE PPGL Coil Performance
- Superior comprehensive properties: Polyester-coated PPGL coil achieves an optimal balance between weather resistance, flexibility, adhesion, color diversity, and cost.
- Superior Weather Resistance & Color Retention: Under typical outdoor conditions, it maintains gloss and color integrity for approximately 8-10 years, resisting chalking and discoloration.
- Exceptional Formability: The flexible PE PPGL coating film adapts well to roll forming, bending, stamping, and perforation processes.
- Rich decorative options: Extensive color selection with multiple surface finishes including high-gloss, matte, textures (e.g., orange peel, sand grain, wood grain), and printed patterns (wood, brick, floral/grass/sky imitations).
- High cost-effectiveness: Compared to premium coatings like PVDF fluorocarbon or HDP high-weatherability, PE coating offers significantly lower costs, making it an ideal choice.
Specifications
| Item | Details |
| Product | PE PPGL coil / Polyester-painted Galvalume Steel Coil |
| Standards | EN 10346, ASTM A755, GB/T 12754 |
| Base Material Specifications | Thickness: 0.15 – 2.0 mm; Width: 600 – 1250 mm; Coil weight as specified |
| Base Material Coating | AZ30 – AZ150 (selectable as required to suit different corrosion environments) |
| Coating Thickness | Front side: 10 – 40 μm; Back side: 5 – 20 μm (customizable) |
| Color Range | Supports customization of the full RAL color chart (e.g., RAL9016 white, RAL7035 gray, RAL5002 blue, etc.); Gloss level adjustable from 20 – 80° |
| Surface Effects | Wrinkle, metallic texture, wood grain, leather, brick-like, natural scenery, etc. |
| Mechanical Properties | Adhesion (cross-cut test) ≥ Grade 1; Impact resistance ≥ 50 kg・cm; Flexibility (T-bend) ≤ T2 |
| Weather Resistance | Service life in indoor environments ≥ 15 years; Service life in mild outdoor environments ≥ 8 years |
Price of PE PPGL Coil
PE PPGL coil is the preferred choice for optimal cost control and excellent performance, priced between $650-900 per ton. Key factors influencing PPGL steel pricing include sheet thickness, metal coating thickness, paint film, and surface finish. Additional processing services such as bending, slitting, forming, or stamping require separate specification. Leave us a message detailing your requirements or application environment to receive a free quote and tailored solution!
PE PPGL Coil Manufacturing
Wanzhi Group‘s coating lines produce full-specification PE polyester-coated PPGI PPGL steel coils, supporting processing into PPGL coils, sheets, strips, panels, profiles, and more.
- Production: From hot-rolled coils to aluzinc substrates and precision coating, Wanzhi Steel Factory maintains full process control across three coating lines.
- Coating: Equipped with high-precision roller coating machines, accurate oven temperature control systems, and online coating thickness/color difference monitors to ensure uniform, stable coatings and support factory acceptance testing.
- Environmental Compliance: Production lines meet environmental standards using eco-friendly coatings.
- Certification: Products comply with international standards including GB, ASTM, and EN.
- Capacity & Delivery: Monthly output of 30,000 tons supports rapid delivery cycles (5-45 days for standard products) with rigorous export packaging (moisture-proof paper, steel corner protectors, etc.).
PE vs. HDP vs. PVDF vs. PPGL Coil Comparison
In extreme industrial or coastal environments with intense UV exposure, high pollution, prolonged high temperatures, and humidity, PE PPGL steelperformance is less stable than HDP PVDF. However, for most residential, industrial, and commercial building applications, PE coating offers the most cost-effective and practical solution.
| Comparison Item | Polyester Coating (PE PPGL coil) | High-Durability Polyester Coating (HDP PPGL coil) | Fluorocarbon Coating (PVDF PPGL coil) |
| Material | Standard polyester resin | High-molecular-weight resin | Polyvinylidene fluoride resin |
| Advantages | Optimal overall cost-effectiveness. | Perfect balance of durability and economy, with significantly better weather resistance than standard PE. | Top-notch weather resistance, excellent color and light retention, anti-pulverization, and self-cleaning properties. |
| Weathering Life | Good | Excellent | Outstanding |
| Processing Performance | Excellent, with the best flexibility | Good, slightly inferior to PE | Moderate, relatively hard; care needed for deep drawing forming |
| Chemical Resistance | Good | Good – Excellent | Extremely excellent |
| Cost | Low | Medium | High |
| Typical Applications | Suitable for most non-harsh environments. | An upgraded choice over PE. | Projects with stringent requirements for long-term appearance. |
Customer Feedback
If you’re selecting prepainted coil for your project and prioritize balancing performance, aesthetics, and budget, PE PPGL coil is your ideal solution!
