Wanzhi Group-premium hot dip galvanized steel factory supplier, produces high quality steel according to EN 10346, including S220 GD,S250GD galvanized steel, DX51D galvanized steel, etc. S250GD+Z is a kind of high-demand structural steel for industrial use in the fields of building structure, automobile manufacturing, home appliances and so on.
Wanzhi S250GD Galvanized Steel
S250GD galvanized steel is a structural hot-dipped galvanized steel with a minimum yield strength of 250 MPa. Zinc thicknesses are usually selected according to the application requirements and include galvanized coils, sheets, roofing sheets, appliance housings and customized tubes and pipes, to name a few. Wanzhi Group supplies various types of hot dip galvanized steel in accordance with EN 10346, ASTM A653 and JIS G3302 standards, welcome to contact us for your steel price.
Specifications
| Material | SGCC,S350GD+Z,S550GD+Z,DX51D,DX52D,DX53D, etc |
|---|---|
| Thickness | 0.12mm-6mm |
| Width | The conventional width below 0.5mm is 1000mm, 1200mm, and above is 1000, 1250mm |
| coil weight | 8-10 tons /customized |
| Tolerance | "+/-0.02 mm |
| Substrate Type | Hot rolled coil, Cold rolled coil |
| Surface structure | Zero spangles, Small spangles, Regular spangles, Big spangles |
| Zinc layer thickness | 30g/㎡-275g/㎡ (Z275/G90) |
| Standard | AISI, ASTM, BS, GB, JIS |
| Implementation standards | GB/T2518 GB/T25052, EN10346, JIS G3302, ASTMA653 |
| Certificates | SGS, ISO 9001,CE |
Mechanical Properties
| Parameter | Standard Requirement | Typical Value |
| Yield Strength (Rp0.2) | ≥250 MPa | 270-310 MPa |
| Tensile Strength (Rm) | 370-460 MPa | 390-440 MPa |
| Elongation (A80mm) | ≥12% | 16-20% |
| Bendability | 180° d=0a | No cracking |
Global Standard Grade Comparison
| Property | Europe EN 10346 | China GB/T 2518 | USA ASTM A653 | Japan JIS G3302 |
| Grade | S250GD+Z | S250GD+Z | SS Grade 40 | SGHC390 |
| Yield Strength | ≥250 MPa | ≥250 MPa | ≥275 MPa | ≥390 MPa |
S250GD Galvanized Steel Advantages and Applications
Ideal for construction, heavy-duty appliances, and transport equipment, S250GD galvanized steel delivers superior weldability, stamping performance, and structural reliability.
Advantages
Enhanced Load Capacity: 250MPa yield strength supports heavier structural loads vs. S220GD.
Corrosion Resistance: Zinc coating (Z20-Z350) of GI steel protects in humid/industrial environments.
Formability: Retains excellent bending/stamping properties for complex part fabrication.
Surface Quality: Uniform coating for painted or exposed architectural applications.
Applications
Construction field: Structural support, roof and wall reinforcement and other components for buildings that need to bear large loads.
Automobile manufacturing field: to meet the demand for automobile lightweight, body parts, chassis structural components, etc..
Home appliance field: shells and structural parts of home appliances with high strength requirements to ensure the stability and durability of home appliances in the process of use.
Others: mechanical parts and equipment shells, electric power towers, communication towers, etc.
S250GD Galvanized Steel Manufacturer
Wanzhi Group’s factory (ISO 9001/14001 certified) has 2 state-of-the-art galvanizing lines, profiling equipment, steel slitting equipment, painted galvanized steel lines as well as sample rooms, laboratories and more. We support SGS, BV and other third-party organizations, and can provide free samples for quality testing.
- Thickness: 0.12-6 mm
- Plating: Zinc (Z), Aluminum-Zinc (AZ), Zinc-Aluminum-Magnesium (ZAM)
- Customization: OEM service for substrate grade, coating weight, size.
- Processing: slitting, punching, bending, painting, profiling (trapezoidal, corrugated, etc.).
- Delivery time: 5-45 days
Customer Feedback
Our S250GD+Z, DX51D+Z, and S350GD+Z products serve 100+ countries across construction, automotive, and industrial sectors, with consistent praise for durability and technical support.
S250GD+Z，S250GD+AZ, S250GD+ZM
| Property | S250GD+Z | S250GD+AZ (Galvalume) | S250GD+ZM (ZAM) |
| Coating | Pure Zinc | 55% Al-43.4% Zn-1.6% Si | Zn + Mg/Al (e.g., ZM310) |
| Corrosion | Good | Excellent | Outstanding |
| Heat Resistance | Moderate | Excellent | High |
| Appearance | Zinc-spangled | Silvery spangled | Dark gray uniform |
| Formability | Excellent | Good (coating harder) | Good (high toughness) |
| Cost | Low | Medium | High |
| Uses | General structures | Roofs, ducts, appliances | Marine, harsh environments |
S250GD+Z VS S350GD+Z
| Property | S250GD galvanized steel | S350GD galvanized steel |
| Yield Strength | ≥250 MPa | ≥350 MPa |
| Tensile Strength | 370–460 MPa | 350–480 MPa |
| Formability | Excellent | Moderate |
| Weldability | Good | Moderate |
| Cost Efficiency | Balanced | Higher material cost |
| Best For | High-formability structures | Ultra-high-strength parts |
Hot products
S250GD galvanized steel offers 15% higher strength than S220GD while maintaining exceptional processability. For extreme corrosion resistance, choose S250GD+AZ/ZM coatings; for critical load-bearing, pair with high-strength substrates. Wanzhi Group tailors solutions to your project – contact us for competitive pricing!
