Z120 Galvanized Steel Sheet

What Is Z120 Galvanized Steel Sheet?

Z120 galvanized steel sheet is steel coated with zinc through a continuous hot-dip galvanizing process. Under EN 10346, “Z” denotes a zinc coating, while “120” indicates a nominal total coating mass of 120 g/m² on both sides. During production, steel strip is cleaned, annealed, and passed through molten zinc, where a controlled zinc layer forms on its surface. The galvanized strip is then processed into sheets by leveling, cutting, and other finishing operations.

Mechanical Properties of Z120 Galvanized Steel Sheet (EN 10346)

Z120 galvanized steel sheet has different mechanical properties depending on the substrate grade. The following values are based on EN 10346; Z120 refers to the zinc coating, while the steel grade determines the mechanical properties.

Steel Grade	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation A80 (%)
DX51D	—	270–500	≥22
DX52D	140–300	270–420	≥26
DX53D	140–260	270–380	≥30
DX54D	120–220	260–350	≥36
S220GD	≥220	≥300	≥20
S250GD	≥250	≥330	≥19
S280GD	≥280	≥360	≥18
S320GD	≥320	≥390	≥17
S350GD	≥350	≥420	≥16
S390GD	≥390	≥460	≥16
S420GD	≥420	≥480	≥15
S450GD	≥450	≥510	≥14
S550GD	≥550	≥560	—

Specification

Product Name	Z120 Galvanized Steel Sheet
Base Material	Cold rolled steel
Zinc Coating	Z120, 120 g/m² total on both sides
Steel Grades	DX51D, DX52D, DX53D, S220GD, S250GD, S280GD, S320GD, S350GD, and more
Standards	ASTM, EN, JIS, GB
Thickness	0.12 mm – 4.0 mm
Width	600 mm – 1,500 mm
Regular Width	914mm, 1000mm, 1219mm, 1220mm, 1250mm
Surface Finish	Regular spangle, minimized spangle, zero spangle, large spangle
Surface Treatment	Skin-passed, oiled, dry, passivated, or chromate-treated
Processing Service	Cutting, slitting, leveling, bending, punching, forming, embossing, and lamination, etc.
MOQ	10 tons
Quality Certificate	SGS, BV, ISO 9001, CE, etc.
Delivery Time	5-45 days
Package	Standard export packaging, or as per your requirements

Spangle Types of Z120 GI Sheet

• Regular Spangle: Visible crystalline zinc patterns formed during hot-dip galvanizing.
• Minimized Spangle: Smaller, less visible zinc crystals for a more uniform surface.
• Zero Spangle: Smooth, spangle-free appearance with no visible zinc crystals.
• Large Spangle: Larger and more pronounced zinc crystals for a distinctive surface appearance.

Advantages of Z120 Galvanized Steel Sheet

• Good Corrosion Resistance: The zinc coating helps protect the steel from moisture and atmospheric corrosion.
• Durable Surface Protection: The continuous zinc coating provides reliable protection for the steel substrate in suitable service environments.
• Good Formability: Suitable steel grades can be bent, formed, punched, and processed for different applications.
• Long Service Life: Zinc protection helps extend the service life of steel under suitable environmental conditions.
• Easy Further Processing: The sheet can be cut, slit, leveled, formed, and fabricated according to project requirements.
• PPGI Substrate: Z120 galvanized steel can be used as a substrate for PPGI production, with an additional organic coating for enhanced protection and appearance.

Z120 Galvanized Steel Sheet Applications

• Roofing and Wall Cladding: Roofing panels, wall panels, and building exteriors.
• Construction: Structural components, framing, ducts, and general building materials.
• Home Appliances: Appliance panels, housings, and internal components.
• Automotive Components: Body parts, brackets, and other corrosion-resistant components.
• Industrial Equipment: Enclosures, equipment parts, and fabricated components.

Z120 Galvanized Steel Sheet for Sale

Wanzhi Group operates two hot-dip galvanizing lines and one electro-galvanizing line. We supply galvanized steel sheets with zinc coating weights from Z30 to Z275 g/m², as well as electro-galvanized steel with coating weights up to 30 g/m². We also supply galvanized steel coils, strips, corrugated sheets, wires, and pipes for industrial, construction, appliance, automotive, and agricultural applications. Standard specifications are available from stock for prompt delivery. Customized products can be delivered within 5–45 working days. Please feel free to contact us for more information.

Z120 Galvanized Steel Sheet Prices

The price of Z120 galvanized steel sheet depends on factors such as steel grade, thickness, width, zinc coating weight, order quantity, and surface finish. The price is USD 600–900 per ton, depending on specifications and market conditions. Zero spangle products require more precise process control and may cost more than regular-spangle products. Leave us a message with the size and quantity you need to get the most competitive price!

Z120 Galvanized Steel Manufacturer and Supplier – Wanzhi Group

Wanzhi Group is a professional galvanized steel manufacturer and supplier in China. Our factory is located in Boxing County, Binzhou, Shandong Province. It is equipped with hot-dip galvanizing lines and high-precision equipment for slitting, leveling, lamination, and coating. We provide galvanized steel sheets and related products with various specifications and processing options, including painting, slitting, cut-to-length, punching, stamping, and forming. Our production and quality management systems are certified to ISO 9001, ISO 14001, and ISO 45001, supporting stable supply and consistent product quality.

Production Capability

Wanzhi Steel operates 8 professional production lines for galvanized steel, galvalume steel, prepainted steel, zinc-aluminum-magnesium steel, and other products, with an annual production capacity of 600,000 tons. To date, we have supplied various metal raw materials and finished products, including GI, GL, PPGI, PPGL, PPAL, ZAM, and stainless steel, to customers in 120+ countries and regions worldwide. Our products are manufactured according to applicable ASTM, GB, JIS, EN, and other international standards.

Export Support

Our factory is located near Qingdao and Tianjin ports, providing a stable supply chain. We accept various trade terms, including FOB, CIF, and EXW, and assist with customs declaration, commodity inspection, and shipping arrangements to support timely delivery.

Packaging

Our galvanized steel sheets and coils are packed in standard export packaging, including plastic film, moisture-resistant paper, galvanized iron sheets, steel strapping, corner protectors, and wooden pallets. The standard packaging features the Wanzhi Group logo. Unbranded or customized packaging is available upon request. We can also provide other packaging options according to customer requirements.

Quality Inspection

Common quality tests for GI steel include dimensional inspection, zinc coating mass and thickness, mechanical properties, surface quality, coating adhesion, and bend testing. Wanzhi provides original Mill Test Certificates (MTC) and supports third-party quality inspections by agencies such as BV and SGS. Free samples are also available for customer reference.

Global Cases

Wanzhi Group supplies galvanized steel with zinc coating designations from Z30 to Z275, including commonly requested Z80, Z100, Z120, and Z275. Higher coating levels, such as Z350, can also be provided upon request. Our products are used in construction, industrial, and infrastructure projects worldwide, with positive customer feedback on quality, service, and delivery.

Wanzhi Group supplies Z120 galvanized steel sheets, coils, strips, and roofing products with customized specifications. Contact us today for samples, technical documents, and a competitive quotation tailored to your requirements.
